100Gbps Full-duplex Transceiver
The X200SC EMBER is a Chip-Scale Package (CSP) surface-mount realization of a 4 TX + 4 RX transceiver optimized for parallel optical data communications at 10 and 25 Gbps per channel.
Product Brief
/ why choose X200SC
The X200SC EMBER Integrates Everything Required
Microcontroller unit (MCU)
Transmitter and Receiver ASICs
GaAs Vertical Cavity Surface Emitting Laser (VCSEL) array
GaAs PIN photodetector (PD) array
Laser/fiber interface optics
Lens guide for registration of the RVCONTM parallel fiber termination
Electrical interface via ball grid array (BGA)
/ more information
Summary Technical Specifications
Parameter
Typical Performance
Comment
Channels
4-Tx + 4-Rx
Parallel channels
Data Rates (per channel)
Up to 28 Gbps
Tested at 10 and 25G
Wavelength
850 nm
TX Power
0 dBm Per Channel
Higher Power Available
Input Voltage Drive
150-1500 mVpp
100 ohm Differential
Receive Sensitivity
-9 dBm
Varies with data rate
AGC
Included in RX
Command Interface
DDMI or UCCI
BIT suite included
Reflow Compatibility
Yes
240 deg c Peak
Temperature Range
-40 to +85 deg C
Wider Temp Range Available
Optical Connector
RVCON
Removable Connector
Size
7.7 X 10 mm
Power Consumption
1W at 25G
3.3V TX and RX
Qualification
Qualified for DoD Applications
/ more information
For further inquiries please contact us
NDA required for family and product specific data sheets.
